Part Number: CR-SSM32/M32/M32



Explanation for Part Numbering (See below for details):



CR-S: Gland with Compound (Barrier) Seal
S : Stainless Steel
F: Female Back End Configuriation
32: Size

M32: Gland shell size
M32: M32 Entry Thread



“CR-S*F” type glands, used in any orientation, are certified Flameproof Ex db, Increased Safety
Ex eb, Restricted Breathing Ex nR and Dust Protected Ex ta. They are suitable for use in Group I
Mining, Zone 1 and 2 for Gas Groups IIA, IIB and IIC and additionally for use in Zones 20, 21 and
22 for Dust Groups IIIA, IIIB and IIIC. Commonly referred to as a “Conduit Stopper Box”, they are
suitable for use with conductors carried in conduit or as a line bushing for terminating flying leads.
They provide a compound barrier Ex db & IP seal on the cable inner cores, eliminating damage
to cables that exhibit “cold flow” characteristics. The unique features include Peppers T-1000, the
sealing compound that enables a quick and easy installation and an innovative barrier chamber that
allows for a full inspection of the compound fill. The gland maintains IP66 & IP68 to 100 metres and
is deluge proof without the use of an additional seal or deluge boot. It is supplied with an IP O-ring
seal as standard on metric entry threads. The gland is supplied with a female conduit connection
thread.



Compliance Standard:
EN 60079-0, EN 60079-1, EN 60079-7, EN 60079-15, EN 60079-31,
IEC 60079-0, IEC 60079-1, IEC 60079-7, IEC 60079-15, IEC 60079-31 & IEC 60529
C22.2 (see certificate), CAN/CSA 60079-0/1/7, UL50



Certification:
ATEX: I M2 II 1D 2G Ex db I Mb / Ex db IIC Gb / Ex eb I Mb / Ex eb IIC Gb / Ex ta IIIC Da
II 3G Ex nR IIC Gc
IECEx: Ex db I Mb / Ex db IIC Gb / Ex eb I Mb / Ex eb IIC Gb / Ex nR IIC Ga / Ex ta IIIC Da
CEC - Canada:
Class I Division 2, Groups A, B, C & D
Class II Division 1, Groups E, F & G
Class I Zone 1 Ex d IIC / Ex e II
Class III, Enclosure Type 4X
EAC: PB Ex d I Mb / 1Ex d IIC Gb X / 1Ex e IIC Gb X / 2Ex nR IIC Gc X / Ex ta IIIC Da X
INMETRO - Brazil: Ex db I Mb / Ex db IIC Gb / Ex eb I Mb / Ex eb IIC Gb / Ex nR IIC Gc / Ex ta IIIC Da
SAC - China: Ex d IIC Gb / Ex e IIC Gb
UKRAINE: I M2 Ex db I Mb / II 2G Ex db IIC Gb / II 2G Ex eb I Mb / II 2G Ex eb IIC Gb
II 3G Ex nR IIC Gc / II 1D Ex ta IIIC Da
CCoE - India: Ex d IIC Gb (Zone 1) / Ex e IIC Gb (Zone 2) / Ex nR IIC Gc (Zone 2)
KCS - Korea: Ex d IIC / Ex e IIC
ABS: Specified ABS Rules
LLOYD’S: Ex d I Mb / Ex d IIC Gb / Ex e I Mb / Ex e IIC Gb / Ex nR IIC Gc / Ex ta IIIC Da
RMRS: Ex d IC / Ex d IIC / Ex e IC / Ex e IIC / Ex ta IIIC



Certificate No.
ATEX: SIRA 03ATEX1479X & SIRA 09ATEX4124X
IECEx: IECEx SIR 07.0098X
CEC - Canada: CSA 1356011
EAC: RU C-GB.BH02.B.00693-18
INMETRO - Brazil: NCC 13.2188 X
SAC - China: NEPSI GYJ16.1401X
UKRAINE: .. 18.0322 X
CCoE - India: PESO P365300/4 & P365300/10
KCS - Korea: 15-GA4BO-0665X & 15-GA4BO-0666X
ABS: 14-LD463991A-1-PDA
LLOYD’S: 10/00056(E1)
RMRS: 14.02755.315



IP Rating: IP66 & IP68 (100 metres - 7 Days), NEMA 4X & DTS01 1991
Temperature: -60oC to +135oC
Materials: Brass or Stainless Steel
Plating: Electroless Nickel
Compound: Peppers T-1000 Sealing Compound



Notes:
* Gland size does not necessarily equate to the entry thread size.
* The IP O-ring seal is only available on metric entry threads. IP washers can be supplied for tapered entry threads.
* Please ensure that the IP O-ring is not used in conjunction with a flat IP washer.
* Dimensions (A) & (B) may differ for glands with non metric entry threads. Please refer to our  Thread Reference Tables for specific dimensions.
* Where glands are fitted into non-metallic Ex e enclosures they must be included within the earth circuit of the system.
* The user should seek expert advice if intending to combine flammable and combustible dust in one environment/installation.
* Assembly instructions must be read prior to installation and adhered to in full.
* Peppers supply cable glands with parallel entry threads that conform to the flameproof threaded joint requirements of IEC/EN 60079-1 and other equivalent standards. They usually incorporate a thread run out according to the available machining techniques and will not have a full form thread for the entire length. Peppers will not be held responsible for clients’ installations where this has not been taken into account.
* To maintain the specified IP rating, clearance holes must be in accordance with EN 50262 Table 1 and the entry device should be suitably secured.
* The gland is supplied with the correct amount of the two-part compound, gloves and instructions to allow one complete termination.
* Gland kits can be supplied with a PTFE IP washer in order to maintain the temperature range if required.
